XDC 180 HD

Collecting lawn tractor with a 240 L grassbag and 98 cm wide cutting deck, suitable to cut grass in big gardens. Powered by a twin-cylinder engine. Pedal-operated hydrostatic drive for easy speed management. Electromagnetic blade engagement clutch for effortless blade management.
  • check Collecting model, with a 240 L grassbag
  • check Powered by a twin-cylinder STIGA ST 550 engine
  • check 98 cm cutting deck with 7 available cutting heights for great flexibility
  • check Electromagnetic blade engagement for easy blade management
  • check Extra-comfort through ergonomically designed seat and soft-grip steering wheel
  • check Battery charger, mulching kit and tow hook not included
Castelgarden XDC 180 HD lawn tractor is made for collecting big quantities of cut grass is powered by a STIGA ST 550 twin-cylinder engine.
The pedal-operated hydrostatic transmission allows an easier and stress-less speed management.
The 98 cm cutting deck is equipped with two blades and anti-scalp wheels. The cutting height can be adjusted to 7 different settings, ranging from 25 to 80 mm, to better adapt any grass condition. The blades are engaged via an electromagnetic clutch, without any effort and without having to push or pull any lever. The grass collector can hold up to 240 litres of clippings, so to ensure long cutting sessions without any need of stopping and emptying the bag. The ergonomically designed seat and soft-grip steering wheel offer extra comfort. The battery charger and Mulching kit are sold separately.
More Information
Shop OnlineNo
Short DescriptionCollecting lawn tractor with a 240 L grassbag and 98 cm wide cutting deck, suitable to cut grass in big gardens. Powered by a twin-cylinder engine. Pedal-operated hydrostatic drive for easy speed management. Electromagnetic blade engagement clutch for effortless blade management.
EAN/UPC8008984851665
Unique selling point 04Electromagnetic blade engagement for easy blade management
Unique selling point 06Battery charger, mulching kit and tow hook not included
Unique selling point 05Extra-comfort through ergonomically designed seat and soft-grip steering wheel
Unique selling point 01Collecting model, with a 240 L grassbag
Unique selling point 0398 cm cutting deck with 7 available cutting heights for great flexibility
Unique selling point 02Powered by a twin-cylinder STIGA ST 550 engine
Key features 1 descriptionThe grassbag can contain up to 240 L of grass cuttings. Long mowing sessions, without stopping.
Key features 1 titleBig grassbag
Key features 2 titleEffortless blade engagement
Key features 2 descriptionBlades can be activated or de-activated through a button. The electormagnetic clutch allows you to manage them without any stress.
Key features 3 titleAdapt the cutting to any grass condition
Key features 3 descriptionThanks to 7 available cutting height settings, the cutting deck can operate from 25 mm up to 80 mm and cut grass in different conditions.
Award 3 logono_selection
Award 2 logono_selection
Award 1 logono_selection
Certification CE logono_selection
FAQ 1 questionWhat is the proper way to clean the lawn tractor after mowing the grass?
FAQ 1 answerThe exterior of the tractor mower must be cleaned with water and detergent, paying attention not to get water in the electrical system, motor and circuit board located under the instrument panel. The collection bag should be emptied and cleaned of residue, then remounted so the cutting assembly can be washed, and then removed, rinsed and allowed to dry. When washing the cutting device assembly and the expulsion chute, the collection bag or rear discharge shield must be fitted, the operator must be seated, the cutting device assembly must be in position “1”, the engine running, transmission placed in neutral and the cutting device must be connected. Then connect a water hose to the appropriate pipe fittings and allow the water to flow for a few minutes while keeping the cutting devices in motion.
FAQ 2 questionWhat action should be carried out before winter storage or before storing it for a period longer than 30 days?
FAQ 2 answerAfter allowing the engine to cool down and fully recharging the battery, disconnect the battery cables and store it in a cool and dry place. Empty the fuel tank, clean the machine thoroughly, check the condition of the cutting device assembly, and, if necessary, contact the service centre. Then store the lawn tractor with the cutting deck in a lowered position, in a sheltered environment and, if possible, covered with a sheet.
FAQ 3 questionWhat action should be carried out before initially using a riding tractor that has been stored over a winter or for a period longer than 30 days?
FAQ 3 answerRefuel it and check the oil level, air filter and petrol filter. Check that the tyres are correctly pressurised and then set up the lawn mower tractor according to how you intend to carry out the mowing (side discharge, collection, rear discharge, mulching). For further information about the preliminary operations and safety checks, please refer to the designated sections of the instructions manual.
FAQ 4 questionWhat standard maintenance operations does the lawn mower tractor need?
FAQ 4 answerBefore each use, we recommend that you perform safety and control checks, check the tyre pressure, and replenish the fuel and oil tank, if necessary. After each use, arrange for a general cleaning of the riding tractor. Please refer to the designated section of the instruction manual (“maintenance table”) for the regular actions recommended to ensure optimal use of the machine.
FAQ 5 questionWhat are the cutting functions of the lawn tractor?
FAQ 5 answerThe riding tractor can be set up in different cutting modes: rear bag collection or rear discharge, or mowing and chopping the grass using the special “mulching kit” function. The mulching cutting system allows you to mow the grass into fine particles, which remain on the lawn, restore nutrients and support growth.
FAQ 6 questionWhat kinds of parts and accessories can the tractor mower be equipped with?
FAQ 6 answerThe lawn tractor can be equipped with various parts and accessories to increase its functions and ensure maximum versatility all year round. For the complete list of parts and accessories, please refer to the relevant product page on the website.
Battery capacity18 Ah
Power10.4 kW
Power sourcePetrol
Engine BrandSTIGA
Engine modelST 550 Twin Powered by STIGA
Displacement586 cm³
Engine rotation speed2600 rpm
Battery Voltage12 V
ChokeManual
Engine coolingAir
Fuel tank capacity6 l
Maximum working area4500.000000
Cutting methodCollecting
Minimum uncut radius70 cm
Cutting width98 cm
Reverse mowingYes
Blade rotationUntimed
Cutting height adjustmentManual with lever
Cutting height positions7 positions
Cutting height range25 - 80 mm
Number of blades2
Blade typeWinged
Additional cutting methodRear discharge, Mulching
Blade engagement typeElectric
TractionRear-wheel drive
Transmission methodPedal-operated
Transmission typeHydrostatic
Collector emptyingManual
Collector capacity240 l
Steering wheelCastelgarden ergonomic
Seat typeCastelgarden classic
Seat adjustmentScrews
DashboardYes with LED
Front wheel size15x6.00-6
Rear wheel size18x8.50-8
Hour meterNo
HeadlightsConventional
Cruise controlNo
BumperYes
Washing linkYes
Collector typeTextile
Storage compartmentYes
Cup holderYes
Pivoting front axleYes
Antiscalp wheels2
Safety systemSeat with Safety Contact Breaker
Mulching kitOptional
Battery chargerOptional
Trailer hitch kitOptional
Measured sound pressure level at operator ear dB(A)86
Measured sound power level dB(A)100
Max vibration on steering wheels (m/s2)8.2
Max vibration on driver's seat (m/s2)0.7
Guaranteed sound power level (LwA) - dB(A)100
Pack weight229 kg
Product length2338 mm
Product width1020 mm
Product height1100 mm
Product weight169.000000
SKU2T2630473/C22
Write Your Own Review
You're reviewing:XDC 180 HD
Your Rating

Key features

Product details and specs

Castelgarden XDC 180 HD lawn tractor is made for collecting big quantities of cut grass is powered by a STIGA ST 550 twin-cylinder engine.
The pedal-operated hydrostatic transmission allows an easier and stress-less speed management.
The 98 cm cutting deck is equipped with two blades and anti-scalp wheels. The cutting height can be adjusted to 7 different settings, ranging from 25 to 80 mm, to better adapt any grass condition. The blades are engaged via an electromagnetic clutch, without any effort and without having to push or pull any lever. The grass collector can hold up to 240 litres of clippings, so to ensure long cutting sessions without any need of stopping and emptying the bag. The ergonomically designed seat and soft-grip steering wheel offer extra comfort. The battery charger and Mulching kit are sold separately.

Technical specs

General info
EAN/UPC8008984851665
SKU2T2630473/C22
Cutting system
Cutting methodCollecting
Minimum uncut radius70 cm
Cutting width98 cm
Reverse mowingYes
Blade rotationUntimed
Cutting height adjustmentManual with lever
Cutting height positions7 positions
Cutting height range25 - 80 mm
Number of blades2
Blade typeWinged
Additional cutting methodRear discharge, Mulching
Blade engagement typeElectric
Transmission
Transmission methodPedal-operated
Transmission typeHydrostatic
Tools kit
Mulching kitOptional
Battery chargerOptional
Trailer hitch kitOptional
Overall dimensions
Pack weight229 kg
Product length2338 mm
Product width1020 mm
Product height1100 mm
Product weight169 kg
Power
Battery capacity18 Ah
Power10.4 kW
Power sourcePetrol
Engine BrandSTIGA
Engine modelST 550 Twin Powered by STIGA
Displacement586 cm³
Engine rotation speed2600 rpm
Battery Voltage12 V
ChokeManual
Engine coolingAir
Fuel tank capacity6 l
Maximum working area4500 ㎡
Drive system
TractionRear-wheel drive
Equipment
Collector emptyingManual
Collector capacity240 l
Steering wheelCastelgarden ergonomic
Seat typeCastelgarden classic
Seat adjustmentScrews
DashboardYes with LED
Front wheel size15x6.00-6
Rear wheel size18x8.50-8
HeadlightsConventional
BumperYes
Washing linkYes
Collector typeTextile
Storage compartmentYes
Cup holderYes
Pivoting front axleYes
Antiscalp wheels2
Safety systemSeat with Safety Contact Breaker
Vibration and noise data
Measured sound pressure level at operator ear dB(A)86
Measured sound power level dB(A)100
Max vibration on steering wheels (m/s2)8.2
Max vibration on driver's seat (m/s2)0.7
Guaranteed sound power level (LwA) - dB(A)100

Support

Support

  • What is the proper way to clean the lawn tractor after mowing the grass?

    The exterior of the tractor mower must be cleaned with water and detergent, paying attention not to get water in the electrical system, motor and circuit board located under the instrument panel. The collection bag should be emptied and cleaned of residue, then remounted so the cutting assembly can be washed, and then removed, rinsed and allowed to dry. When washing the cutting device assembly and the expulsion chute, the collection bag or rear discharge shield must be fitted, the operator must be seated, the cutting device assembly must be in position “1”, the engine running, transmission placed in neutral and the cutting device must be connected. Then connect a water hose to the appropriate pipe fittings and allow the water to flow for a few minutes while keeping the cutting devices in motion.

    What action should be carried out before initially using a riding tractor that has been stored over a winter or for a period longer than 30 days?

    Refuel it and check the oil level, air filter and petrol filter. Check that the tyres are correctly pressurised and then set up the lawn mower tractor according to how you intend to carry out the mowing (side discharge, collection, rear discharge, mulching). For further information about the preliminary operations and safety checks, please refer to the designated sections of the instructions manual.

    What are the cutting functions of the lawn tractor?

    The riding tractor can be set up in different cutting modes: rear bag collection or rear discharge, or mowing and chopping the grass using the special “mulching kit” function. The mulching cutting system allows you to mow the grass into fine particles, which remain on the lawn, restore nutrients and support growth.

    What action should be carried out before winter storage or before storing it for a period longer than 30 days?

    After allowing the engine to cool down and fully recharging the battery, disconnect the battery cables and store it in a cool and dry place. Empty the fuel tank, clean the machine thoroughly, check the condition of the cutting device assembly, and, if necessary, contact the service centre. Then store the lawn tractor with the cutting deck in a lowered position, in a sheltered environment and, if possible, covered with a sheet.

    What standard maintenance operations does the lawn mower tractor need?

    Before each use, we recommend that you perform safety and control checks, check the tyre pressure, and replenish the fuel and oil tank, if necessary. After each use, arrange for a general cleaning of the riding tractor. Please refer to the designated section of the instruction manual (“maintenance table”) for the regular actions recommended to ensure optimal use of the machine.

    What kinds of parts and accessories can the tractor mower be equipped with?

    The lawn tractor can be equipped with various parts and accessories to increase its functions and ensure maximum versatility all year round. For the complete list of parts and accessories, please refer to the relevant product page on the website.
