XDL 210 HD

Lawn tractor made for side-discharge, ideal to manage overgrown and wild grass, thanks to the 108 cm wide cutting deck and side discharge funnel. Powered by a twin-cylinder engine. Pedal-operated hydrostatic drive for easy speed management. Powerful headlights for enhanced visibility of the area to be cut.

Side-discharge lawn tractor, perfect for wild or overgrown grass
Powered by a twin-cylinder STIGA ST 550 engine
108 cm cutting deck with 7 available cutting heights for great flexibility
Easy speed management, thanks to pedal-operated hydrostatic transmission
Powerful headlights, for improved visibility
Mulching kit available separately

Skip to the beginning of the images gallery

Castelgarden XDL 210 HD lawn tractor is made for cutting big quantities of tall or wild grass and side discharging it. This strong lawn tractor is powered by a STIGA ST 550 twin-cylinder engine.
The pedal-operated hydrostatic transmission allows an easier and stress-less speed management.
The 108 cm cutting deck is equipped with two blades, that can be activated through a simple button, and anti-scalp wheels. The cutting height can be adjusted to 7 different settings, ranging from 25 to 80 mm, to better adapt any grass condition. The powerful hedalights allow to work also in low-light conditions.
The battery charger and mulching kit are sold separately.

More Information
Shop Online	No
Short Description	Lawn tractor made for side-discharge, ideal to manage overgrown and wild grass, thanks to the 108 cm wide cutting deck and side discharge funnel. Powered by a twin-cylinder engine. Pedal-operated hydrostatic drive for easy speed management. Powerful headlights for enhanced visibility of the area to be cut.
EAN/UPC	8008984851726
Unique selling point 06	Mulching kit available separately
Unique selling point 01	Side-discharge lawn tractor, perfect for wild or overgrown grass
Unique selling point 05	Powerful headlights, for improved visibility
Unique selling point 04	Easy speed management, thanks to pedal-operated hydrostatic transmission
Unique selling point 03	108 cm cutting deck with 7 available cutting heights for great flexibility
Unique selling point 02	Powered by a twin-cylinder STIGA ST 550 engine
Key features 1 title	Perfect for overgrown or wild grass
Key features 1 description	This lawn tractor has a special side funnel, created to discharge cut grass without any risk of blockage, even with very tall and wet grass.
Key features 2 title	Cutting height is adjustable as preferred
Key features 2 description	Thanks to 7 available cutting height settings, the cutting deck can operate from 25 mm up to 80 mm and cut grass in different conditions.
Award 1 logo	no_selection
Award 2 logo	no_selection
Award 3 logo	no_selection
Certification CE logo	no_selection
Power	10.8 kW
Battery capacity	18 Ah
Power source	Petrol
Engine Brand	STIGA
Engine model	ST 550 Twin Powered by STIGA
Displacement	586 cm³
Engine rotation speed	2800 rpm
Battery Voltage	12 V
Choke	Manual
Engine cooling	Air
Fuel tank capacity	6 l
Maximum working area	7000.000000
Cutting method	Side discharge
Minimum uncut radius	65 cm
Cutting width	108 cm
Reverse mowing	Yes
Blade rotation	Untimed
Cutting height adjustment	Manual with lever
Cutting height positions	7 positions
Cutting height range	25 - 80 mm
Number of blades	2
Blade type	Mulching
Additional cutting method	Mulching
Blade engagement type	Electric
Traction	Rear-wheel drive
Transmission method	Pedal-operated
Transmission type	Hydrostatic
Steering wheel	Castelgarden ergonomic
Seat type	Castelgarden classic
Seat adjustment	Screws
Dashboard	No
Front wheel size	15x6.00-6
Rear wheel size	18x8.50-8
Hour meter	No
Headlights	Conventional
Cruise control	No
Bumper	Yes
Washing link	Yes
Storage compartment	Yes
Cup holder	Yes
Pivoting front axle	Yes
Antiscalp wheels	2
Safety system	Seat with Safety Contact Breaker
Mulching kit	Optional
Battery charger	Optional
Trailer hitch kit	Optional
Guaranteed sound power level (LwA) - dB(A)	100
Max vibration on steering wheels (m/s2)	3
Max vibration on driver's seat (m/s2)	1.2
Measured sound pressure level at operator ear dB(A)	87
Measured sound power level dB(A)	99
Pack weight	205.5 kg
Product length	1726 mm
Product width	1315 mm
Product height	1100 mm
Product weight	160.000000
SKU	2T1220473/C22

Write Your Own Review

XDL 210 HD

Find a distributor

Key features

Product details and specs

Technical specs

General info

EAN/UPC	8008984851726
SKU	2T1220473/C22

Cutting system

Cutting method	Side discharge
Minimum uncut radius	65 cm
Cutting width	108 cm
Reverse mowing	Yes
Blade rotation	Untimed
Cutting height adjustment	Manual with lever
Cutting height positions	7 positions
Cutting height range	25 - 80 mm
Number of blades	2
Blade type	Mulching
Additional cutting method	Mulching
Blade engagement type	Electric

Transmission

Transmission method	Pedal-operated
Transmission type	Hydrostatic

Tools kit

Mulching kit	Optional
Battery charger	Optional
Trailer hitch kit	Optional

Overall dimensions

Pack weight	205.5 kg
Product length	1726 mm
Product width	1315 mm
Product height	1100 mm
Product weight	160 kg

Power

Power	10.8 kW
Battery capacity	18 Ah
Power source	Petrol
Engine Brand	STIGA
Engine model	ST 550 Twin Powered by STIGA
Displacement	586 cm³
Engine rotation speed	2800 rpm
Battery Voltage	12 V
Choke	Manual
Engine cooling	Air
Fuel tank capacity	6 l
Maximum working area	7000 ㎡

Drive system

Traction	Rear-wheel drive

Equipment

Steering wheel	Castelgarden ergonomic
Seat type	Castelgarden classic
Seat adjustment	Screws
Front wheel size	15x6.00-6
Rear wheel size	18x8.50-8
Headlights	Conventional
Bumper	Yes
Washing link	Yes
Storage compartment	Yes
Cup holder	Yes
Pivoting front axle	Yes
Antiscalp wheels	2
Safety system	Seat with Safety Contact Breaker

Vibration and noise data

Guaranteed sound power level (LwA) - dB(A)	100
Max vibration on steering wheels (m/s2)	3
Max vibration on driver's seat (m/s2)	1.2
Measured sound pressure level at operator ear dB(A)	87
Measured sound power level dB(A)	99

Support

Manuals

Engine manual Download

User manual Download

Additional sheet Download
