XF 135 HD

Compact and easy-to-use ride-on mower, made for collecting grass in medium gardens, thanks to the 72 cm cutting deck and 170L collector bag. Powered by a STIGA single-cylinder engine. Mulching kit is available separately.
  • check Compact collecting ride-on mower with a 170L collector bag
  • check Powered by a STIGA single-cylinder engine
  • check 72 cm cutting deck with 7 available cutting positions, from 30 to 80 mm
  • check Ergonomic steering wheel enhances driving pleasure
  • check Mulching kit available separately
Castelgarden XF 135 HD ride-on mower is made for collecting grass thanks to its 170L bag. This compact and performing lawn tractor is powered by a STIGA single-cylinder engine.
The 72 cm cutting deck is equipped with two blades. The cutting height can be adjusted to 7 different settings, ranging from 30 to 80 mm, to better adapt any grass condition. The collector bag can contain up to 170 L of cut grass. The ergonomic steering wheel allows a more comfortable working. The mulching kit is sold separately.
More Information
Shop OnlineNo
Short DescriptionCompact and easy-to-use ride-on mower, made for collecting grass in medium gardens, thanks to the 72 cm cutting deck and 170L collector bag. Powered by a STIGA single-cylinder engine. Mulching kit is available separately.
EAN/UPC8008984851221
Unique selling point 04Ergonomic steering wheel enhances driving pleasure
Unique selling point 05Mulching kit available separately
Unique selling point 01Compact collecting ride-on mower with a 170L collector bag
Unique selling point 0372 cm cutting deck with 7 available cutting positions, from 30 to 80 mm
Unique selling point 02Powered by a STIGA single-cylinder engine
Key features 1 descriptionThis ride-on mower's compact dimensions and structure make it even easier to manage.
Key features 1 titleCompact and easy-to-drive
Key features 2 titleCutting height is adjustable as preferred
Key features 2 descriptionThanks to 7 available cutting height settings, the cutting deck can operate from 30 mm up to 80 mm and cut grass in different conditions.
Award 3 logono_selection
Award 2 logono_selection
Award 1 logono_selection
Certification CE logono_selection
FAQ 1 questionWhat is the proper way to clean the lawn tractor after mowing the grass?
FAQ 1 answerThe exterior of the tractor mower must be cleaned with water and detergent, paying attention not to get water in the electrical system, motor and circuit board located under the instrument panel. The collection bag should be emptied and cleaned of residue, then remounted so the cutting assembly can be washed, and then removed, rinsed and allowed to dry. When washing the cutting device assembly and the expulsion chute, the collection bag must be fitted, the operator must be seated, the cutting device assembly must be in position “1”, the engine running, transmission placed in neutral and the cutting device must be connected. Then connect a water hose to the appropriate pipe fittings and allow the water to flow for a few minutes while keeping the cutting devices in motion.
FAQ 2 questionWhat action should be carried out before winter storage or before storing it for a period longer than 30 days?
FAQ 2 answerAfter allowing the engine to cool down and fully recharging the battery, disconnect the battery cables and store it in a cool and dry place. Empty the fuel tank, clean the machine thoroughly, check the condition of the cutting device assembly, and, if necessary, contact the service centre. Then store the lawn tractor with the cutting deck in a lowered position, in a sheltered environment and, if possible, covered with a sheet.
FAQ 3 questionWhat action should be carried out before initially using a riding tractor that has been stored over a winter or for a period longer than 30 days?
FAQ 3 answerRefuel it and check the oil level, air filter and petrol filter. Check that the tyres are correctly pressurised and then set up the lawn mower tractor according to how you intend to carry out the mowing (side discharge, collection, rear discharge, mulching). For further information about the preliminary operations and safety checks, please refer to the designated sections of the instructions manual.
FAQ 4 questionWhat standard maintenance operations does the lawn mower tractor need?
FAQ 4 answerBefore each use, we recommend that you perform safety and control checks, check the tyre pressure, and replenish the fuel and oil tank, if necessary. After each use, arrange for a general cleaning of the riding tractor. Please refer to the designated section of the instruction manual (“maintenance table”) for the regular actions recommended to ensure optimal use of the machine.
FAQ 5 questionWhat are the cutting functions of the lawn tractor?
FAQ 5 answerThe riding tractor can be set up in different cutting modes: rear bag collection, or mowing and chopping the grass using the special “mulching kit” function. The mulching cutting system allows you to mow the grass into fine particles, which remain on the lawn, restore nutrients and support growth.
FAQ 6 questionWhat kinds of parts and accessories can the tractor mower be equipped with?
FAQ 6 answerThe lawn tractor can be equipped with various parts and accessories to increase its functions and ensure maximum versatility all year round. For the complete list of parts and accessories, please refer to the relevant product page on the website.
Battery capacity18 Ah
Power6.5 kW
Power sourcePetrol
Engine BrandSTIGA
Engine modelST 350 Powered by STIGA
Displacement352 cm³
Engine rotation speed2800 rpm
Battery Voltage12 V
ChokeManual
Engine coolingAir
Fuel tank capacity4 l
Maximum working area2500.000000
Cutting methodCollecting
Minimum uncut radius70 cm
Cutting width72 cm
Reverse mowingYes
Cutting height adjustmentManual with lever
Cutting height positions7 positions
Cutting height range30 - 80 mm
Number of blades1
Additional cutting methodMulching
Blade engagement typeManual
TractionRear-wheel drive
Transmission methodLever-operated
Transmission typeHydrostatic
Collector emptyingManual
Collector capacity170 l
Steering wheelCastelgarden ergonomic
Seat typeCastelgarden classic
Seat adjustmentScrews
DashboardYes with LED
Front wheel size11x4.00-4
Rear wheel size15x6.00-6
Hour meterNo
HeadlightsConventional
Cruise controlNo
BumperNo
Washing linkYes
Collector typeTextile
Cup holderNo
Pivoting front axleYes
Antiscalp wheelsNo
Safety systemSeat with Safety Contact Breaker
Mulching kitOptional
Battery chargerOptional
Trailer hitch kitNot applicable
Measured sound pressure level at operator ear dB(A)85.1
Measured sound power level dB(A)99
Max vibration on steering wheels (m/s2)3.14
Max vibration on driver's seat (m/s2)0.99
Guaranteed sound power level (LwA) - dB(A)100
Pack weight193.5 kg
Product length1858 mm
Product width745 mm
Product height1122 mm
Product weight161.000000
SKU2T0210473/C22
Write Your Own Review
You're reviewing:XF 135 HD
Your Rating

Key features

Product details and specs

Castelgarden XF 135 HD ride-on mower is made for collecting grass thanks to its 170L bag. This compact and performing lawn tractor is powered by a STIGA single-cylinder engine.
The 72 cm cutting deck is equipped with two blades. The cutting height can be adjusted to 7 different settings, ranging from 30 to 80 mm, to better adapt any grass condition. The collector bag can contain up to 170 L of cut grass. The ergonomic steering wheel allows a more comfortable working. The mulching kit is sold separately.

Technical specs

General info
EAN/UPC8008984851221
SKU2T0210473/C22
Cutting system
Cutting methodCollecting
Minimum uncut radius70 cm
Cutting width72 cm
Reverse mowingYes
Cutting height adjustmentManual with lever
Cutting height positions7 positions
Cutting height range30 - 80 mm
Number of blades1
Additional cutting methodMulching
Blade engagement typeManual
Transmission
Transmission methodLever-operated
Transmission typeHydrostatic
Tools kit
Mulching kitOptional
Battery chargerOptional
Trailer hitch kitNot applicable
Overall dimensions
Pack weight193.5 kg
Product length1858 mm
Product width745 mm
Product height1122 mm
Product weight161 kg
Power
Battery capacity18 Ah
Power6.5 kW
Power sourcePetrol
Engine BrandSTIGA
Engine modelST 350 Powered by STIGA
Displacement352 cm³
Engine rotation speed2800 rpm
Battery Voltage12 V
ChokeManual
Engine coolingAir
Fuel tank capacity4 l
Maximum working area2500 ㎡
Drive system
TractionRear-wheel drive
Equipment
Collector emptyingManual
Collector capacity170 l
Steering wheelCastelgarden ergonomic
Seat typeCastelgarden classic
Seat adjustmentScrews
DashboardYes with LED
Front wheel size11x4.00-4
Rear wheel size15x6.00-6
HeadlightsConventional
Washing linkYes
Collector typeTextile
Pivoting front axleYes
Safety systemSeat with Safety Contact Breaker
Vibration and noise data
Measured sound pressure level at operator ear dB(A)85.1
Measured sound power level dB(A)99
Max vibration on steering wheels (m/s2)3.14
Max vibration on driver's seat (m/s2)0.99
Guaranteed sound power level (LwA) - dB(A)100

Support

Support

  • What is the proper way to clean the lawn tractor after mowing the grass?

    The exterior of the tractor mower must be cleaned with water and detergent, paying attention not to get water in the electrical system, motor and circuit board located under the instrument panel. The collection bag should be emptied and cleaned of residue, then remounted so the cutting assembly can be washed, and then removed, rinsed and allowed to dry. When washing the cutting device assembly and the expulsion chute, the collection bag must be fitted, the operator must be seated, the cutting device assembly must be in position “1”, the engine running, transmission placed in neutral and the cutting device must be connected. Then connect a water hose to the appropriate pipe fittings and allow the water to flow for a few minutes while keeping the cutting devices in motion.

    What action should be carried out before initially using a riding tractor that has been stored over a winter or for a period longer than 30 days?

    Refuel it and check the oil level, air filter and petrol filter. Check that the tyres are correctly pressurised and then set up the lawn mower tractor according to how you intend to carry out the mowing (side discharge, collection, rear discharge, mulching). For further information about the preliminary operations and safety checks, please refer to the designated sections of the instructions manual.

    What are the cutting functions of the lawn tractor?

    The riding tractor can be set up in different cutting modes: rear bag collection, or mowing and chopping the grass using the special “mulching kit” function. The mulching cutting system allows you to mow the grass into fine particles, which remain on the lawn, restore nutrients and support growth.

    What action should be carried out before winter storage or before storing it for a period longer than 30 days?

    After allowing the engine to cool down and fully recharging the battery, disconnect the battery cables and store it in a cool and dry place. Empty the fuel tank, clean the machine thoroughly, check the condition of the cutting device assembly, and, if necessary, contact the service centre. Then store the lawn tractor with the cutting deck in a lowered position, in a sheltered environment and, if possible, covered with a sheet.

    What standard maintenance operations does the lawn mower tractor need?

    Before each use, we recommend that you perform safety and control checks, check the tyre pressure, and replenish the fuel and oil tank, if necessary. After each use, arrange for a general cleaning of the riding tractor. Please refer to the designated section of the instruction manual (“maintenance table”) for the regular actions recommended to ensure optimal use of the machine.

    What kinds of parts and accessories can the tractor mower be equipped with?

    The lawn tractor can be equipped with various parts and accessories to increase its functions and ensure maximum versatility all year round. For the complete list of parts and accessories, please refer to the relevant product page on the website.

Compatible Products

Related Accessories

  1. MULCHING KIT 72 CM
    MULCHING KIT 72 CM
    original mulching plug for riders. Includes muclhing plug. Ideal to be used throughout Spring and Summer.
  2. MULCHING KIT WITH BLADE 72 CM
    MULCHING KIT WITH BLADE 72 CM
    original mulching kit for garden tractors. Includes muclhing blade and plug. Ideal to be used throughout Spring and Summer.
