BE
BE- | Castelgarden
2,668.60€
SKU
2F5820243/C20
| Shop Online | No |
|---|---|
| EAN/UPC | 8008984847491 |
| Award 1 logo | no_selection |
| Award 2 logo | no_selection |
| Award 3 logo | no_selection |
| Certification CE logo | no_selection |
| Power | 7.1 kW |
| Battery capacity | 18 Ah |
| Power source | Petrol |
| Engine Brand | STIGA |
| Engine model | ST 400 Powered by STIGA |
| Displacement | 414 cm³ |
| Engine rotation speed | 3200 rpm |
| Battery Voltage | 12 V |
| Choke | Manual |
| Engine cooling | Air |
| Fuel tank capacity | 4.2 l |
| Easy refill | Yes |
| Engine Oil tank capacity | 1.2 l |
| Maximum working area | 2500.000000 |
| Cutting method | Combi - switch between Multiclip mulching and rear discharge |
| Cutting width | 85 cm |
| Deck lift | Manual |
| Cutting height adjustment | Manual |
| Service position | Yes |
| Traction | Rear-wheel drive |
| Maximum speed forward | 9 km/h |
| Transmission method | Pedal-operated |
| Transmission type | Hydrostatic |
| Steering wheel | With spinner |
| Steering type | Articulated |
| Power assisted steering | Not available |
| Seat type | Castelgarden classic |
| Seat adjustment | Locking knobs |
| Seat adjustable underweight | No |
| Dashboard | No |
| Front wheel size | 14.3x5.60-8 |
| Rear wheel size | 14.3x5.60-8 |
| Hour meter | No |
| Headlights | No |
| Cruise control | No |
| PTO engagement | Electromagnetic |
| Auxiliary hydraulic outlets | No |
| Storage compartment | Seat column pocket |
| Cup holder | No |
| Trailer hitch kit | Included |
| Guaranteed sound power level (LwA) - dB(A) | 100 |
| Max vibration on driver's seat (m/s2) | 0.6 |
| Measured sound pressure level at operator ear dB(A) | 87 |
| Max vibration on steering wheels (m/s2) | < 2.4 |
| Measured sound power level dB(A) | 99 |
| Pack weight | 218 kg |
| Weight | 179.000000 |
| Product weight without battery | 171.8 kg |
| Product length | 1681 mm |
| Product width | 770 mm |
| Product height | 1171 mm |
| SKU | 2F5820243/C20 |
Write Your Own Review
Technical specs
General info
| EAN/UPC | 8008984847491 |
|---|---|
| SKU | 2F5820243/C20 |
Cutting system
| Cutting method | Combi - switch between Multiclip mulching and rear discharge |
|---|---|
| Cutting width | 85 cm |
| Deck lift | Manual |
| Cutting height adjustment | Manual |
| Service position | Yes |
Transmission
| Transmission method | Pedal-operated |
|---|---|
| Transmission type | Hydrostatic |
Tools kit
| Trailer hitch kit | Included |
|---|
Overall dimensions
| Pack weight | 218 kg |
|---|---|
| Weight | 179 kg |
| Product weight without battery | 171.8 kg |
| Product length | 1681 mm |
| Product width | 770 mm |
| Product height | 1171 mm |
Power
| Power | 7.1 kW |
|---|---|
| Battery capacity | 18 Ah |
| Power source | Petrol |
| Engine Brand | STIGA |
| Engine model | ST 400 Powered by STIGA |
| Displacement | 414 cm³ |
| Engine rotation speed | 3200 rpm |
| Battery Voltage | 12 V |
| Choke | Manual |
| Engine cooling | Air |
| Fuel tank capacity | 4.2 l |
| Easy refill | Yes |
| Engine Oil tank capacity | 1.2 l |
| Maximum working area | 2500 ㎡ |
Drive system
| Traction | Rear-wheel drive |
|---|---|
| Maximum speed forward | 9 km/h |
Equipment
| Steering wheel | With spinner |
|---|---|
| Steering type | Articulated |
| Power assisted steering | Not available |
| Seat type | Castelgarden classic |
| Seat adjustment | Locking knobs |
| Front wheel size | 14.3x5.60-8 |
| Rear wheel size | 14.3x5.60-8 |
| PTO engagement | Electromagnetic |
| Storage compartment | Seat column pocket |
Vibration and noise data
| Guaranteed sound power level (LwA) - dB(A) | 100 |
|---|---|
| Max vibration on driver's seat (m/s2) | 0.6 |
| Measured sound pressure level at operator ear dB(A) | 87 |
| Max vibration on steering wheels (m/s2) | < 2.4 |
| Measured sound power level dB(A) | 99 |
